STEERING



             MAIN STATION DUAL ENGINE MERCRUISER                 DUAL ENGINE TIE BAR KIT
             ELECTRONIC STEERING




                  8M0134373
             Kit includes components necessary to install electronic steering, including
             Mercury's award winning electronic steering helm.  This is particulary beneficial
             and intended for large, non‑planing vessels such as houseboats that may be 80+
             feet in length.  The addition of a VesselView 502 or higher adds autopilot capability.
             Dual engine main station DTS Bravo 2 or 3 sterndrive gas or diesel engine
             applications.  Due to autopilot calibration, this is intended for non‑planing hulls only.
             SECOND STATION DUAL ENGINE MERCRUISER                     96708A 4
             ELECTRONIC STEERING                                 Used with power steering cylinder mounted on the port transom plate. Adjusts from
                  8M0134374                                      29 in.(737 mm) to 37‑1/2 in.(952 mm)
             Kit includes components necessary to install electronic steering, including  Fits 1983 and newer R/MR/Alpha One/Gen II and Bravo models, except D7.3L
             Mercury's award winning electronic steering helm.  This is particulary beneficial  diesel.
             and intended for large, non‑planing vessels such as houseboats that may be 80+
             feet in length.  The addition of a VesselView 502 or higher adds autopilot capability.  JET DRIVE 135 & 270 DEG. STEERING SYSTEM
             Dual engine second station DTS Bravo 2 or 3 sterndrive gas or diesel engine
             applications.  Due to autopilot calibration, this is intended for non‑planing hulls only.
                                                                 The 135 deg. system allows 135 degrees rotation of the steering wheel
             MAIN STATION DUAL ENGINE MERCRUISER                 (3/8 turn lock to lock). The 270 deg. system allows 270 degrees rotation
             ELECTRONIC STEERING W/ BASIC JOYSTICK               of the steering wheel (3/4 turn lock to lock).Order helm, bezel, and
                84-8M0143706                                     steering cable separately.  If the size required is not listed, use the next
             Kit includes components necessary to install electronic steering, including  larger size.
             Mercury's award winning electronic steering helm.  This is particulary beneficial
             and intended for large, non‑planing vessels such as houseboats that may be 80+
             feet in length.  Also includes basic joystick functionality by integrating the engines  STEERING HELM
             with the thrusters on the boat.  This system utilizes the same joystick as dual
             engine JPI.  The addition of a VesselView 502 or higher adds autopilot capability.
             Dual engine main station DTS Bravo 2 or 3 sterndrive gas or diesel engine
             applications.  Due to autopilot calibration, this is intended for non‑planing hulls only.
             SECOND STATION DUAL ENGINE MERCRUISER
             ELECTRONIC STEERING W/ BASIC JOYSTICK
                84-8M0143707
             Kit includes components necessary to install electronic steering, including
             Mercury's award winning electronic steering helm at a second station.  This is
             particulary beneficial and intended for large, non‑planing vessels such as
             houseboats that may be 80+ feet in length.  Also includes basic joystick
             functionality by integrating the engines with the thrusters on the boat.  This system
             utilizes the same joystick as dual engine JPI.  The addition of a VesselView 502 or  809486
             higher adds autopilot capability.                   135 Degree Steering Helm.
             Dual engine second station DTS Bravo 2 or 3 sterndrive gas or diesel engine
             applications.  Due to autopilot calibration, this is intended for non‑planing hulls only.  Fits all Sport Jet models, except V‑6 models.
                                                                 STEERING HELM
             MERCRUISER DUAL ENGINE TIE BAR KITS

             DUAL ENGINE TIE BAR KIT









                                                                      850699
                                                                 270 Degree Steering Helm.
                                                                 Fits all Jet Drive models
                   92020A 2
             Used with power steering cylinder mounted on the starboard transom plate. Adjusts
             from 30 in.(762 mm) to 46 in.(1168 mm)
             Fits 1983 and newer R/MR/Alpha One/Gen II and Bravo models, except D7.3L
             diesel.
                   92020A 3
             Used with power steering cylinder mounted on the starboard transom plate. Adjusts
             from 46 in.(1168 mm) to 62 in.(1575 mm)                                                                  STEERING
             Fits 1983 and newer R/MR/Alpha One/Gen II and Bravo models, except D7.3L
             diesel.



             Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets.   677
             For more information, please contact your local Mercury, Mariner, MerCruiser or
             Quicksilver Office.
