Page 792 - Quicksilver Accesories Guide 2019

MERCURY RACING PROPELLER TYPE

BRAVO I LAB FINISHED 48-8M0073456
15.25 X 23 Pitch RH SS Polished Lab Finished
Mercury Racing Polished Lab Finished Bravo I propellers are designed 48-831909L65
for high‑performance, 250 ‑ 400R four stroke outboard and Bravo I, 15.25 X 22 Pitch LH SS Polished Lab Finished
Sport and Sport Master sterndrive applications. Excellent top speeds, 48-831910L65
great handling, good mid‑range speeds and great planing performance 15.25 X 22 Pitch RH SS Polished Lab Finished
for Vee, Cats and Step hulls.
Hub kits sold separately, 835258K2 for 1 inch and 840389K06 for 1.25 MAX 5 LAB FINISHED
inch propshaft.
BRAVO I LAB FINISHED PROPELLER 300‑600 HP
Mercury Racing Lab Finished MAX 5 blade is designed for high
performance Outboard Center Console and Cats with high gearcase
height. Sterndrive Sport Deck, Cats and Modified Cats also benefit from
enhanced top speeds, great handling, good mid‑range throttle response
and quick planing performance.
With a diameter of 15 inches and having 5 blades, the Max 5 holds
more water and offers less slip than it's 4 blade counterparts. For the
1.25 inch prop shaft use 840389K06 HD Hub kit and for 1 inch prop
shaft use hub kit 835258K2.

48-831919L45 MAX 5 PROPELLER
15.25 X 33 Pitch LH SS Polished Lab Finished
48-831920L45 MERCURY RACING PROPELLER TYPE
15.25 X 33 Pitch RH SS Polished Lab Finished
48-831919L65
15.25 X 32 Pitch LH SS Polished Lab Finished
48-831920L65
15.25 X 32 Pitch RH SS Polished Lab Finished
48-831917L45
15.25 X 31 Pitch LH SS Polished Lab Finished
48-831918L45
15.25 X 31 Pitch RH SS Polished Lab Finished
48-831917L65 48-8M0118017
15.25 X 30 Pitch LH SS Polished Lab Finished 15 x 34 Pitch LH, SS Polished LAB
48-831918L65 48-8M0118016
15.25 X 30 Pitch RH SS Polished Lab Finished 15 x 34 Pitch RH, SS Polished LAB
48-831915L45 48-8M0118015
15.25 X 29 Pitch LH SS Polished Lab Finished 15 x 33.5 Pitch LH, SS Polished LAB
48-831916L45 48-8M0118014
15.25 X 29 Pitch RH SS Polished Lab Finished 15 x 33.5 Pitch RH, SS Polished LAB
48-831915L65 48-8M0118013
15.25 X 28 Pitch LH SS Polished Lab Finished 15 x 33 Polished LH, SS Polished LAB
48-831916L65 48-8M0118012
15.25 X 28 Pitch RH SS Polished Lab Finished 15 x 33 Pitch RH, SS Polished LAB
48-831913L45 48-8M0131167
15.25 X 27 Pitch LH SS Polished Lab Finished 15 x 32.8 Pitch LH, SS Polished LAB
48-831914L45 48-8M0131166
15.25 X 27 Pitch RH SS Polished Lab Finished 15 x 32.8 RH, SS Polished LAB
48-831913L65 48-8M0131165
15.25 X 26 Pitch LH SS Polished Lab Finished 15 x 32.3 Pitch LH, SS Polished LAB
48-831914L65 48-8M0131164
15.25 X 26 Pitch RH SS Polished Lab Finished 15 x 32.3 Pitch RH, SS Polished LAB
48-831911L45 48-8M0118011
15.25 x 25 Pitch LH SS Polished Lab Finished 15 x 32 Pitch LH, SS Polished LAB
48-831912L45 48-8M0118010
15.25 x 25 Pitch RH SS Polished Lab Finished 15 x 32 Pitch RH, SS Polished LAB
48-831911L65 48-8M0118009
15.25 X 24 Pitch LH SS Polished Lab Finished 15 x 31.5 Pitch LH, SS Polished LAB
48-831912L65 48-8M0118008
15.25 X 24 Pitch RH SS Polished Lab Finished 15 x 31.5 Pitch RH, SS Polished LAB
48-8M0073457 48-8M0118007
15.25 X 23 Pitch LH, SS Polished Lab Finished 15 x 31 Pitch LH, SS Polished LAB

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 785
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
