ELECTRICAL ACCESSORIES

Battery Boxes

Meet ABYC standard E-10 and U.S. Coast Guard Specification Number 183.420 as an OEM-
installed battery hold-down system. Polypropylene construction for total acid resistance.
Hold-down straps resist 350 lbs. of force, nearly four times the USCG requirement. Drop tested in
temperatures ranging from -20°F to +120°F. Mounting hardware included. 9082 9065

Small Battery Box
For smaller batteries like Series 16 and those used in jet skis, power lawn, and garden equipment.
Vented black battery box (5-7/8 inch maximum battery block height, 7-7/8 inch maximum battery height with terminals).
Standard Battery Box
Vented and non-vented battery box for standard size, Series 24 batteries (8-3/16 inch maximum battery block height,
10-1/8 inch maximum battery height with terminals).
Note: 9069 cover is non-vented and is not for marine use.
• Four cable openings, enlarged to .55 inch-diameter
• Larger handles with rolled edges 9067
• Instructions molded inside cover

Power Guard 27 Battery Box
Vented black battery box for Series 27 batteries (8-1/2 inch maximum battery block height, 10-1/2 inch maximum
battery height with terminals).
• Four cable openings, enlarged to .55 inch-diameter
• Larger handles with rolled edges
• Instructions molded inside cover
Large Battery Box
Vented black battery box for larger applications (7-15/16 inch maximum battery block height, 9-3/4 inch maximum
battery height with terminals).
9084
Power Box, F27 Series
• LED battery level indicator with one-touch test button
• Heavy duty non-corrosive black plastic box
• Hold-down strap included
• 12-volt DC accessory adapter port with 10-amp fuse built-in
• External terminals

Dimensions with Lid Installed
Battery Box Battery Inside Dim. Outside Dim. Strap Bulk Prop
Description Series (L x W x H) (L x W x H) Length Color/Style Packaging 65
Small U1 10-5/8” x 7” x 10-1/8” 11" x 7-1/2" x 8-3/4" 40" Black, vented 9082-1
Standard 24/24M/24F 10-5/8” x 7” x 10-1/8” 14" x 9-5/8" x 10-5/8" 40" Black, vented 9065-1
Black, 9069-1
non-vented
Power Guard 27 27/27F/27M 13-1/16” x 6-15/16” x 16-7/8" x 9-5/8" x 10-7/8" 40" Black, vented 9067-1
10-1/2”
Large 29/31 15-7/16” x 6-15/16” x 18-3/4" x 9-1/4" x 10-1/4" 38" Black, vented 9084-1
9-3/4”
Power Box 27F — — 44" Black 9076-1

9076
