Page 172 - Attwood Marine Products Collection 2020

CLEATS

& ACCESSORIES

Neat Cleat

The Neat Cleat design offers what you’ve been asking for — a retractable
cleat with a thin profile that installs easily on narrow gunwales. Friction springs
• Beautiful, strong and durable – each stanchion is a 7/8" rod of solid hold cleat up at
Enhanced 316 Stainless Steel alloy any position
• Cleats stay up when pulled
• Backed by a lifetime warranty against corrosio
Installation is simple and quick – just drill twice with an appropriate size Drainage receptacles
hole saw. Drainage receptacles (included) capture moisture and send it to capture moisture
the bilge via pitot tubing (not included). Attwood recommends (included)
using only stainless steel fasteners for stainless steel hardware. Two hole mounting
pattern for easy
installation

66515

A B C D E F G H Installation
Above Above Between Hole Max.
Total Total Deck Deck Line Stan- Thread Install. Saw Hull Bulk Prop Aftermarket Prop
Length Width Lowered Raised Opening chions Length Depth Size Thickness Packaging 65 Packaging 65
NEAT CLEAT
4-1/2" 1-5/16" 1/2" 1-5/8" 1-1/4" 1-3/4" 1-3/4" 3-1/8" 1" 1" 66515-1 66515-7
6" 1-1/2" 1/2" 1-5/8" 1-1/4" 2-1/4" 1-3/4" 3-1/8" 1" 1" 66517-1 66517-7
8" 1-15/16" 3/4" 2" 1-3/8" 2-13/16" 2-1/4" 3-3/4" 1" 1-1/2" 66519-1 —
10" 2-7/16" 13/16" 2-5/8" 1-5/8" 3-1/2" 2-7/8" 5-1/4" 1" 1-1/2" 66538-1 —

Neat Cleat Accessories

Bulk Prop Aftermarket Prop
Description Packaging 65 Packaging 65
BACKING PLATES
For 4-1/2" Neat Cleat 66529-1 —
For 6" Neat Cleat or Combo Cleat 66531-1 —
For 8" Neat Cleat or Combo Cleat 66533-1 —
SPACERS 66529
For 6" Neat Cleat or Combo Cleat 66617-1 —

For our Stainless Steel Thru-Hulls and Scuppers see Pages 17-20.

CLEATS & ACCESSORIES

170 HARDWARE
