LIFT RINGS

Lift Ring

Attwood’s stern-mounted lift ring provides
heavy-duty strength for boats lifted by davits,
cranes or shore stations. Lifts a maximum
vertical load of 12,000 lbs. Installs with 1/2"
countersunk stainless steel screws and
washers, which must be through-bolted with
locking washers or locking nuts.
Warning: Lift rings are designed to lift a boat only when fastened to the boat structure. The maximum lifting load figures listed were determined by applying a test 66120
load in the direction of the eye shank axis, with the shank fixed in an immovable testing device. Listed lifting loads are for reference only.

Bulk Aftermarket
Description Packaging Packaging
Stainless steel lift ring 66120-1 —

Flush Lift Rings

Flush lift ring with 3/4" I.D. handle fits most hatches, cabinets, and drawers. Maintains a flush appearance, neatly
recesses for safety. Pre-drilled with four holes for required fasteners.

Fastener Bulk Prop Aftermarket Prop
Description Flange Size Quantity Packaging 65 Packaging 65
Brass 1-7/8" L x 1-1/2" W #6 fasteners (4) — 3326-3

3326
Large Flush Lift Ring, Brass

Large lifting ring allows a full grip. Provides strength for lifting 3" 3" 2-3/8" 2-3/8"
large and heavy hatch covers. Flush appearance, neatly recessed 5/16" 5/16"
for safety. Chrome-plated brass. Pre-drilled with four holes for
#6 fasteners.
2-1/8" 2-1/8"

3325
Fastener Bulk Prop Aftermarket Prop
Description Flange Size Handle Size Quantity Packaging 65 Packaging 65
Brass 3" L x 2-1/4" W 2" L x 3/4" I.D. ring #6 fasteners (4) — 3325-3
