เอกสารอ้างอิง Network_10G ข้อ 4.3

EX4600 Ethernet Switch

EX4600 Switch Specifications • Number of LAGs: 128
Hardware 4.3.5 • Number of ports per LAG: 32
• Switching capacity: 1.44 Tbps/1.07 Bpps • FCoE scale:
• Weight: 21.7 lb (9.84 kg) with PSUs and fans installed - Number of FCoE VLANs/FC virtual fabrics: 4,095
• Dimensions (HxWxD): 1.72 x17.36 x 20.48 in • Firewall filters: 4,000
(4.37 x 44.09 x 52.02 cm) • IPv4 unicast routes: 128,000 prefixes; 208,000 host
**
• Switching mode: Cut-through and store-and-forward routes; 64 ECMP paths
• Front-to-back or back-to-front airflow (for hot aisle/cold • IPv4 multicast routes: 104,000
aisle deployment) • IPv6 multicast routes: 52,000
• Management and rear console port connections • IPv6 unicast routes: 64,000 prefixes
• Predicted mean time between failures (MTBF): 150,000 • Address Resolution Protocol (ARP) entries: 48,000
hours
• Jumbo frame: 9,216 bytes 4.3.9
• Predicted FIT rate: 4,987 Access Control Lists (ACLs)
Interface Options • Port-based ACL (PACL): Ingress and egress
• 1GbE SFP: 24(40) (with 10GbE expansion modules) • VLAN-based ACL (VACL): Ingress and egress
• 10GbE SFP+: 24(40/72) (with 10GbE expansion modules/ • Router-based ACL (RACL): Ingress and egress
with fixed 40GbE ports using breakout cables) 4.3.3 • ACL entries (ACE) in hardware per system:
• 40GbE QSFP+: 4(12) (with expansion modules) - Ingress ACL: 1,536
- Each fixed QSFP+ port can be configured as a 4x10GbE - Egress ACL: 1,024
interface • ACL counter for denied packets
- Each QSFP+ port can be configured as a 40 Gbps port • ACL counter for permitted packets
- USB port • Ability to add/remove/change ACL entries in middle of list
- Console port 4.3.16 (ACL editing)
- 2 management ports: 1 RJ-45 and 1 SFP • L2-L4 ACL
- Supported transceiver and direct attach cable • IPv6 ACL
- SFP+ 10GbE optical modules • Firewall filter on loopback interface
- SFP+ DAC cables: 1/3/5 m direct-attached copper and • Firewall filter on management interface
1/3/5/7/10 m active direct-attached copper Spanning Tree Protocol (STP)
- SFP GbE optical and copper module • Multiple Spanning Tree Protocol (MSTP) instances: 64
- QSFP+ to SFP+ 10GbE direct attach break-out copper • VLAN Spanning Tree Protocol (VSTP) instances: 253
(1/3 m direct-attached copper cable)
Traffic Mirroring
Rack Installation Kit • Mirroring destination ports per switch: 4
• Versatile four post mounting options for 19-in server rack
or datacom rack • Maximum number of mirroring sessions: 4
Airflow • Mirroring destination VLANs per switch: 4
• Front-to-back and back-to-front cooling Layer 2 Features
• Redundant variable-speed fans to reduce power draw • STP—IEEE 802.1D (802.1D-2004)
• Power Supply and Fan Modules 4.3.15 • Rapid Spanning Tree Protocol (RSTP) (IEEE 802.1w); MSTP
• Dual redundant (1+1) and hot-pluggable power supplies (IEEE 802.1s)
• 110-240 V single phase AC power • Bridge protocol data unit (BPDU) protect
• -36 to -72 V DC power • Loop protect
• Redundant (N+1) and hot-pluggable fan modules for front- • Root protect
to-back and back-to-front airflow • RSTP and VSTP running concurrently
Performance Scale (Unidimensional) • VLAN—IEEE 802.1Q VLAN trunking
• Routed VLAN interface (RVI)
• MAC addresses per system: 4.3.7
288,000 * • Port-based VLAN
• MAC address filtering
** Roadmap
Page 8 of 20 8
