Page 311 - เอกสารตรวจรับระบบ dr site

เอกสารอ้างอิง Network_10G ข้อ 4.3

EX4600 Ethernet Switch

• FCoE transit switch (FIP snooping ACL installation) • Ethernet-over-MPLS (L2 circuit)
• Virtual fiber channel gateway • Layer 3 VPN (L3VPN)
• FCoE session path learning • Layer 2 VPN (L2VPN)
• FCoE session health monitoring • Link protection
• Graceful restart for FIP snooping • MPLS fast reroute (FRR)- 1:1 Protection
• FC-BB-6 VN2VN snooping • Node-link protection
Virtual Chassis Management and Operations
• 40GbE and 10GbE as Virtual Chassis port • Junos Space Network Director **
• Virtual Chassis Routing Engine (RE) election • Role-based CLI management and access
• Virtual Chassis pre-provisioning (plug and play) • CLI via console, telnet, or SSH 4.3.12
• Auto-LAG formation of Virtual Chassis ports • Extended ping and traceroute
• Mixed Virtual Chassis support between EX4300-EX4600 • Junos OS configuration rescue and rollback 4.3.11
(in data center only) • Image rollback
• FCoE transit across Virtual Chassis members • SNMP v1/v2/v3
• QoS on Virtual Chassis ports • Junos XML management protocol
• Local designated forwarding • sFlow v5
• Graceful RE switchover (GRES) • DHCP server
• Nonstop routing (NSR) • DHCP relay on L2 VLAN & L3 interfaces (with option 82)
• Nonstop bridging (NSB) • DHCP local server support
• Monitor distributed aggregate interface • High frequency statistics collection
• Control plane protection for virtual RE • Beacon LED for port and system
High Availability • Automation and orchestration
• ISSU (in standalone and MC-LAG configuration) • Zero touch provisioning (ZTP)
• Bidirectional Forwarding Detection (BFD) • OpenStack Neutron Plug-in
• Uplink failure detection (UFD) • Puppet
• Graceful Routing Engine switchover (GRES) in Virtual • Chef
Chassis configuration • Junos OS event, commit, and operations scripts
• Non-stop bridging (NSB) in Virtual Chassis configuration • Ability to execute scripts written in Python/TCL/Perl
• Non-stop routing (NSR) in Virtual Chassis configuration
• Non-stop software upgrade (NSSU) in Virtual Chassis Traffic Mirroring
configuration • Port-based
• LAG port
MPLS
• VRF-Lite • VLAN-based
• 2-label stack • Filter-based
• Static label-switched paths (LSPs) • Mirror to local
• RSVP-based signaling of LSPs • Local/L2 remote analyzer (SPAN, RSPAN for IPv4 and IPv6
frames)
• LDP-based signaling of LSPs • Mirror to remote destinations (L2 over VLAN)
• LDP tunneling (LDP over RSVP)
• Insight Technology (microburst monitoring and statistics
• MPLS class of service (CoS) reporting)
• MPLS access control list (ACL)/policers Standards Compliance
• MPLS LSR support IEEE Standards
• Push, swap, pop, IP lookup • IEEE 802.1D
• IPv6 tunneling (6PE) (via IPv4 MPLS backbone)
• IEEE 802.1w
• MPLS Operation, Administration, and Maintenance • IEEE 802.1
(OAM)—
• LSP ping • IEEE 802.1Q
• IPv4 L3VPN (RFC 2547, 4364) ** Roadmap

Page 10 of 20 10
