Chapter 1: Overview
Figure 4 on page 25 shows the port panel of an EX4600 switch.
Figure 4: EX4600 Switch Port Panel
1— Electrostatic Discharge (ESD) terminal 3—40 GbE ports (4)
2—10 G ports (24) 4—Expansion module bays with cover panels
(2)
Access Port and Uplink Port LEDs on an EX4600 Switch 4.3.14
The Link/Activity and Status LED configuration for an EX4600 switch uses bi-colored
LEDs. The two figures in this topic show the location of those LEDs:
• Figure 5 on page 25 shows the location of the LEDs on the SFP+ access ports on the
EX4600 and Figure 6 on page 25 shows the location of the LEDs on the QSFP+ uplink
ports on the EX4600.
Figure 5: LEDs on the SFP+ Ports
Figure 6: LEDs on the QSFP+ Ports
Bi-colored LEDs
