Page 232 - B2B all year round_UPDATE 5

6 Product - WINLINE Best EV/EVSE Solution

● Power Module

40kW 1,000V Power Module 30kW 1,000V Power Module
Model : NXR100040 Model : NXR100030
AC Input : 285~475V/75A AC Input : 285~475V
DC Output : 20~1,000V , 0~133.3A DC Output : 20~1,000V , 0~100A
Power : 40kW Power : 30kW

15kW 500V Power Module 20kW 500V Power Module 20kW 750V Power Modue

Model : NXR50030 Model : NXR50040 Model : NXR75030
AC Input : 260~475V AC Input : 260~475V AC Input : 260~475V
DC Output : 200~550V, 35A DC Output : 200~500V, 46.5A DC Output : 200~750V, 33A
Power : 15kW Power : 20kW Power : 20kW

※ Please refer to the detailed data product catalog.
