6 Product - Yazaki Best EV/EVSE Solution
● CHAdeMO Inlet & Connector
Inlet Charging Connector
Specifications Specifications
Certifying body : UL / TUV Rheinland Standard : UL / IEC62196-1/ CSA C22.2
Standard : UL2251 / IEC62196-1 Rated voltage : DC500V
Rated voltage : DC500V Rated current : 125A
Rated current : 125A Ambient temperature : -40’C ~ 60’C
Number of poles : POWER2 SIGNAL7 Cabtire cable : POWER2 SIGNAL7 Lock Circuit 2
Ambient temperature : -40’C ~ 60’C
