tAGS • 3d viewS 955

tags. See also elevation tags views, 132–140
annotations walls, 476
inserting tags, 766, 766–767, 767, 792–793, 885 template-selection dialog box, 333
overview, 765–766 Temporary Apply Template Properties, 30
using tags, 765–771 Temporary Dimension Properties dialog box,
CAD-based symbols compared to, 142 72, 72
door tags, 143, 143–146, 144, 145 Temporary Dimension Text Appearance setting, 72
section tags, 146, 146–149, 147, 149 temporary dimensions, 71, 71–72. See also
text vs. labels, 142–143 dimensions
view tags, 145, 145, 146 Temporary Hide/Isolate command, 29, 68, 176, 913
Target Percentage Glazing, 343, 343, 344, 350 Temporary View Properties, 30, 30–31
Target Percentage Skylights, 344 tenant exercise, 402–416. See also design options;
Target Sill Height, 344 groups; phasing
teamwork. See worksharing Design Options tool, 413, 413–415, 414, 415
Tekla BIMsight, 261, 264 existing floor plan, 403
templates (project templates), 107–157 Phase 1: Demolition, 404, 404–405, 405
additive template approach, 151, 152, 476 Phase 1: Proposed, 405–406, 406
annotations, 141–150, 157, 871 Phase 2: Demolition, 407, 407–408, 408
Bottom Line, 157, 871–872 Phase 2: Proposed, 408–409, 409
color schemes, 130–132 scheduling, 410–413, 411, 412, 413
configuring, 107–108 Terminations, top rail type properties, 631
create from scratch, 108, 108 text. See also dimensions; keynotes; labels
fill patterns, 124–130 annotations, 750–754
custom complex fill patterns, 126–130, contextual text formatting, 752–754, 753
157, 871 Format Panel, 752–754, 753
Fill Patterns dialog box, 124, 127, 695 introduction, 749, 749–750, 750
importing custom fill patterns, 127–130, 871 using, 750–752, 751, 752
graphic quality/consistency settings, 108–132 labels vs., 142–143
line patterns, 112, 112–113, 113, 114 Text command, 750, 750
line styles, 114, 114–115 Thermal tab, Material Browser, 116, 118, 119
line weights, 111, 111 thick floor finishes, 551–553, 552, 553
object styles, 108–110 thin floor finishes, 550–551, 551
introduction, 107–108 3D (analytic) extents
management strategies, 151–156, 872 explaining, 39, 39–41, 40, 41
materials, 115–124 resetting or maximizing, 43, 43–44
path selection for, 151, 151 3D model data
redundant work reduction, 154 Bentley Structural Modeler, 246, 267, 875
schedules added, 738 exporting, 258–267, 875
sharing template data inserted
Insert 2D Elements From File, 155–156, 156, using as face, 243–246, 244, 245, 246
713, 713 using as mass, 242–243
Insert Views From File, 154, 155, 156, 715, 872, using as object, 246–248, 248
884 3D views, 59–62
Transfer Project Standards, 122, 140, 152–154, copy, 909
153, 476, 491, 625, 680, 872 extents, 62, 62
start project with custom template, 151, 151, presenting designs, 834–837
157, 872 annotating, 837, 837
subtractive template approach, 152, 152, 476 Auto-Section Box tool, 836
view filters, 135–137 orienting to other views, 834–836, 835, 836
view templates, 137–140 selecting, 59, 59
