Tank-Mounted Return Line Filter GR

Features and Benefits 100 gpm IRF
■ Patented GeoSeal Elements 380 L/min TF1
®
®
■ Various Dirt Alarm options
■ Cost optimized for in-tank applications 100 psi KF3
■ Plastic bowl and cap lower cost and minimize weight
7 bar
KL3

LF1–2"

MLF1

RLD

GRTB

MTA

MTB

Model No. of filter in photograph is GRTB1KBGZ10S. ZT

Applications KFT

RT

RTI

LRT

ART

BFT

QT

KTK

LTK

MRT
Flow Rating: Up to 100 gpm (380 L/min) for 150 SUS (32 cSt) fluids Filter
Max. Operating Pressure: 100 psi (7 bar) Housing Accessories
Temp. Range: -20°F to 225°F (-29°C to 107°C) Specifications for Tank-
Bypass Setting: Cracking: 25 psi (1.7 bar) Mounted
Full Flow: 42 psi (2.9 bar) Filters
Cap & Bowl: Nylon
Porting Head: Aluminum
Weight of GRTB-1K: 5.3 lbs (2.4 kg) NOTES: PAF1
Element Change Clearance: 12” (305 mm) The GRTB is a
basic filter. For MAF1
more complex
applications, use
the standard RT MF2
filter.

SCHROEDER INDUSTRIES 239
