Page 396 - Wago_AutomationTechnology_Volume3_2015_US.pdf

5 I/O-System — 750 XTR Series
394 General Product Information

Superior reliability in extreme climates Additional protection against interference
Taking it to the eXTReme — Automation systems are increasingly being pulses
The standard for 750 XTR located in outdoor and remote locations where The WAGO-I/O-SYSTEM 750 XTR provides
The WAGO-I/O-SYSTEM 750 XTR components are directly affected by widely fluctu- greater isolation up to 5 kV of impulse voltage,
is readily recognizable by its dark gray ating temperatures conditions (e.g., wind turbines lower EMC emission of interference and higher
modules. Benefit from the unique features insensitivity against EMC interference. These
offered by this system in extreme environ- and transformer stations). strengths add up to trouble-free operation.
ment applications. Whether freezing cold, extreme heat or high
humidity, the WAGO-I/O-SYSTEM 750 XTR is
High mechanical performance
The WAGO-I/O-SYSTEM 750 XTR engineered for absolute dependability in all Automation systems must be particularly vibration-
features outstanding characteristics: It is climatic conditions. This robust XTR version of the resistant, especially when installed close to vibrati-
extremely temperature-resistant, immune WAGO-I/O-SYSTEM 750 is unfazed by both on-prone and shock-generating system compon-
to interferences, as well as insensitive to freezing cold down to -40 °C and scorching heat ents. Powerful motors and power circuit breakers
vibrations and impulse voltages. This is up to +70 °C. And this applies to both initial are just two examples of common disturbance-cre-
what makes 750 XTR the first choice for start-up and daily operation. ating components. The WAGO-I/O-SYSTEM 750
demanding applications, including: Another highlight is that the 750 XTR functions at XTR is also setting new standards for automation
• Marine systems and onshore/offshore elevations up to 5,000 m, opening up these ap- systems with 5g of vibration resistance according
installations to DIN EN 60068-2-6 (acceleration: 50 m/
• Renewable energy systems plications to new highs for safety, reliability and s ) and 15g (150 m/s ) or 25g (250 m/s ) of
2
2
2
(wind, photovoltaic and performance — even in the thin air of a mountain continuous shock resistance according to IEC
biogas plants) top station. 60068-2-27.
• Transformer stations and Count on long-lasting, trouble-free operation
power distribution eXTRreme evolution of the tried and tested and industry-topping levels of safety — even in
• Petrochemical industry Using an industry-leading platform, the WAGO- the most torturous applications, such as a tunnel
• Water and wastewater treatment I/O-SYSTEM 750 XTR boasts the same proven boring machines.
systems benefits:
• Custom machine engineering • Compact design: up to 16 channels in just one Worldwide approvals
• Railway applications International approvals for industrial automation,
12 mm module
shipbuilding and onshore/offshore applica-
• Easy to use
®
• CAGE CLAMP spring connection technology tions guarantee worldwide use even under the
harshest operating conditions, e.g., Germanischer
for vibration-proof, fast and maintenance-free
Lloyd, Det Norske Veritas, American Bureau of
connections
Shipping, Korean Register of Shipping, Nippon
• Fieldbus independence due to its modular
Kaiji Kyokai, Registro Italiano Navale and Polski
design Rejestr Stratkow.
• Clear identification with the WAGO WSB
marking system

g
r

& /

● No air conditioning required
- Compact footprint
- Lower energy and maintenance costs
● Can be used in unshielded areas
● Maximum system uptime
● Install close to vibrating and shock-generating system components
● CAGE CLAMP connection technology for vibration-proof,
®
fast and maintenance-free connection
