WINSTA Radio Receivers 8
553

4-channel radio receiver 2-channel radio receiver
with 4 make contacts with sunblind outputs

The 4-channel radio receiver is used to switch 4
independent electrical devices. The 2-channel radio
receiver has 2 sunblind outputs that can be controlled
independently from each other. The radio receiver
processes telegrams transmitted by switches using
EnOcean radio technology (STM modules). The outputs
are switched via relay contacts.

• Radio receiver for battery-less and wireless sensors
• LED indication of switch status
• External antenna for optimum transmission range
Illustration and block diagram for 770-629/101-000
(required)
• Frequency band 868 MHz
L PE N
• Transmitter-to-receiver assignment via learn mode
• The state of outputs can be predefined for a power K1...K4
failure scenario EnOcean
Receiver
• Wire connection using WINSTA connectors
LRN
A1...A4
WINSTA ®
4-channel radio receiver ...
L PE N L PE N
Description Item No. Pack. Item No. Pack.
Unit Unit
®
WINSTA radio receiver 770-629/101-000 1 770-629/102-000 1

Technical Data 8
Voltage supply 230 V AC, 50 Hz ... 60 Hz, max. 16 A 230 V AC, 50 Hz ... 60 Hz, max. 16 A
Voltage range ± 10 % ± 10 %
Current consumption (internal) max. 21 mA max. 21 mA
Number of channels 4 2
Output current (per channel) max. 16 A / 4 A 2 A motor load
Total current max. 16 A max. 4 A
Inrush current max. 120 A / 50 ms 25 A
Type of load resistive / lamp load resistive / inductive
Switching frequency max. 5 Hz max. 5 Hz
Isolation isolated internal voltage supply isolated internal voltage supply
2500 V impulse withstand voltage 2500 V impulse withstand voltage
Fuse protection External, 16 A max. External, 16 A max.
Ambient operating temperature 0°C ... +55°C 0°C ... +55°C
Storage temperature -25 °C ... +85 °C -25 °C ... +85 °C
Relative air humidity (no condensation) 85% 85%
Degree of pollution 2 2
Degree of protection IP20 IP20
Mounting position any any
Dimensions (mm) W x H x L 190 x 145 x 30 190 x 145 x 30
Type of mounting Wall screw adapter Wall screw adapter
Standards/specifications Vibration and shock resistance acc. to IEC 60068-2-6 and Vibration and shock resistance acc. to IEC 60068-2-6 and
IEC 60068-2-27 IEC 60068-2-27
Accessories: RF magnetic antenna incl. 3m connecting
cable with SMA connector 758-910 758-910
Connection accessories WINSTA connectors Input: socket, 3 poles, e.g. 770-103; 4-channel Input: socket, 3 poles, e.g. 770-103; 2-channel
output: plug, 3 poles, e.g. 770-113 output: plug, 4 poles, e.g. 770-114
