750-103
1 750/753 Series Marker Carrier
676
<____________________________________ 104,5 ____________________________________>
<_____ 23 _____>
< 11,5 >
The hinged 750-103 Marker Carrier allows group marking of
WAGO-I/O-SYSTEM 750/753 Series components, while featuring a large
area for self-marking.
The marker carrier can be accommodated in the upper miniature WSB carrier
plate.
Description Item No. Pack. Technical Data
Unit
750/753 Series Marker Carrier 750-103 50 Dimensions (in mm)
Width 11.5 mm
Length 104.5 mm
Material Polycarbonate
Weight 2.84 g
Accessories Item No. Pack.
Unit
Marker strips for thermal transfer printer
(plain; white; 7.5mm/0.29in wide;
50m roll) 709-178 1
Markers for marker carriers
(plain; white; DIN A4 sheets with
removable strips 52 x 8.5mm/0.33in;
99 pieces/sheet) 750-105 500
