Accessories Vacuum Suction Cups
Filter Discs FD
PA01019111_inh_EN.pdf Diameter (Ø) from 16 mm to 55 mm PA01019111_inh_EN.pdf

container
Suitable for Industry Specific Applications
Schmalz - The Company

container
Applications
• Filter disc to protect the vacuum system from dust and dirt, Vacuum Knowledge
without changing the flow resistance
• Filter disc prevents the workpiece from being pilled into the
suction cup Suction Cups
Vacuum

Special Grippers

Vacuum Grip- ping Systems
Filter discs FD
container
Design

• Filter disc (1) made of porous polyethylene (sinter PE)
Mounting
• Filtration grade 120 µm Elements
• Can be placed directly into the suction cup (2)

Vacuum Generators

Valve Technology

System design filter discs FD
Switches and
container
Our Highlights... Your Benefits... Monitoring
• Placed directly in a fold of the >Dirt and dust is filtered out
suction cup directly at the workpiece
• Wide variety of diameters >Wide range of application Filters and Connections
possibilities for suction cup
series FGA and FG
• Stable filter disc >High intrinsic stability of the
suction cup; stops the work-
piece from being sucked in Services

Contact
Bellows suction cups with filter discs FD being used for handling wooden boards
