Accessories Vacuum Suction Cups
Suction Cup Inserts SPI PEEK
PA01019111_inh_EN.pdf Suction area (Ø) from 6 mm to 32 mm PA01019111_inh_EN.pdf

container
Schmalz - The Company Suitable for Industry Specific Applications

container
Applications
Vacuum Knowledge • Suction cup inserts for gentle and mark-free gripping and
depositing of smooth workpieces
• Application with crystalline solar cells, thin-film modules and
wafers / substrates in the semiconductor area
Vacuum Suction Cups • Handling of glass such as display glass, thin glass with thickness
< 0.1 mm or coated glass without leaving a chemical fingerprint
by elastomers

Special Grippers • Use in combination with bellows suction cups FGA (1.5 folds) and
FG (2.5 folds)

Vacuum Grip- ping Systems Suction cup inserts SPI PEEK for bellows suction cups Our Highlights... Your Benefits...

container
Design

• Suction cup inserts made of PEEK with support structure and • Suction cup inserts made of >Non-marking and gentle
Mounting Elements vacuum channels PEEK handling of thin, flat
workpieces without leaving
• Inserts are tool-free clipped into the lower suction cup fold of
bellows suction cups chemical fingerprints
• Structure with defined contact >Defined and low surface
Vacuum Generators area, flow grooves and pressure on the workpiece
surface
vacuum channels

• Smart vacuum distribution on >High leakage compensation
for high effective suction
the suction surface
Valve Technology forces
• Clip-in assembly in suction >Quick and easy installation
cups without tools
and replacement
Switches and Monitoring • Even sealing surface >Low stress in the workpiece

container
Designation Code Suction Cup Inserts SPI PEEK
Filters and Connections container Abbreviated designation Diameter Material

in mm
Example SPI 9 PEEK:
SPI 9 6 PEEK
PEEK Polyetheretherketon
SPI
Services to
32

container Ordering Data Suction Cup Inserts SPI PEEK
Contact
Suction cup insert SPI PEEK is delivered with the desired diameter.
container

Index of Products

300 www.schmalz.com/spi-peek
