Accessories Vacuum Suction Cups
Suction Cup Covers SU
PA01019111_inh_EN.pdf Diameter (Ø) from 30 mm to 360 mm PA01019111_inh_EN.pdf

container

container Design Data Suction Cup Covers SU Schmalz - The Company

Vacuum Knowledge

Vacuum Suction Cups

Special Grippers
SU 30 to 360

container
Type Dimensions in mm
d D D2 D3 Vacuum Grip- ping Systems
SU 30 3 30 - -
SU 40 3 40 - -
SU 50 5 50 30 -
SU 70 5 70 30 -
SU 80 5 80 30 - Mounting Elements
SU 100 6 100 50 -
SU 120 6 120 50 -
SU 160 6 160 50 -
SU 210 6 210 50 - Vacuum Generators
SU 230 6 230 50 -
SU 280 6 280 50 -
SU 300 6 300 90 170
SU 360 6 360 90 170
