Accessories Vacuum Suction Cups
Sealing Rings DR-MOS SI
PA01019111_inh_EN.pdf Diameter (Ø) from 20 mm to 88 mm PA01019111_inh_EN.pdf

container

container Designation Code Sealing Rings DR-MOS SI Schmalz - The
Abbreviated designation Dimensions Height Material and Company
in mm in mm Shore hardness
Example DR 20/10x2 MOS SI-15:
DR 20/10 x2 MOS SI-15
DR 20/10 to 88/64 outside/inside x2 MOS SI-15 silicone Knowledge
x5 Vacuum

container
Ordering Data Sealing Rings DR-MOS SI Suction Cups
Vacuum
Sealing profile DR-MOS SI is delivered with the desired characteristics.
container

Available accessories: silicone adhesive
Special
container Grippers
Sealing Rings DR-MOS SI
container
Type Part Number
DR 20/10x2 MOS SI-15 10.01.06.02618 Vacuum Grip- ping Systems
DR 22.5/13x2 MOS SI-15 10.01.06.02614
DR 32/19x2 MOS SI-15 10.01.06.02615
DR 42/20x5 MOS SI-15 10.01.06.02616
DR 52/33x5 MOS SI-15 10.01.06.02548
DR 62/42x5 MOS SI-15 10.01.06.02617 Mounting Elements
DR 78/54x5 MOS SI-15 10.01.06.02619
DR 88/64x5 MOS SI-15 10.01.06.02620

container
Ordering Data Accessories Sealing Rings DR-MOS SI Vacuum Generators
container
Type Part Number
Silicone adhesive (90 ml tube) 27.03.04.00003
Valve Technology
container
Technical Data Sealing Rings DR-MOS SI
Switches and
container
Type For suction cup type* Material-Type Temperature resistance [°C] Colour
DR 20/10x2 MOS SI-15 FGA 20 Foam rubber 180 beige Monitoring
DR 22.5/13x2 MOS SI-15 FGA-22, FGA-25, FG-25 Foam rubber 180 beige
DR 32/19x2 MOS SI-15 FGA-33, FG-32 Foam rubber 180 beige
DR 42/20x5 MOS SI-15 FGA-43, FG-42 Foam rubber 180 beige
DR 52/33x5 MOS SI-15 FGA-53, FG-52 Foam rubber 180 beige Filters and Connections
DR 62/42x5 MOS SI-15 FGA-63, FG-62 Foam rubber 180 beige
DR 78/54x5 MOS SI-15 FGA-78 Foam rubber 180 beige
DR 88/64x5 MOS SI-15 FG-88 Foam rubber 180 beige
*Suitable for the silicone suction cup types listed
Services

Contact

Index of Products

container
www.schmalz.com/dr-mos
