Overview of Section 4
Special Grippers
PA01019111_inh_EN.pdf At a Glance Page PA01019111_inh_EN.pdf

container
Selection Aid
container Schmalz - The
Selection by Workpiece 316 Company

Vacuum Knowledge

container
Floating Suction Cups Suction Cups
Vacuum
container
Floating Suction Cups SBS 317

• Diameter: 20 to 120 mm Floating suction cup for low-contact handling of fragile Special Grippers
• Holding force: 2.0 to 104.0 N workpieces such as paper, film, printed circuit boards or
• Rubber buffer on the bottom side of the wafers and solar cells.
suction cup
container Vacuum Grip- ping Systems
Magnetic Grippers

Magnetic Grippers SGM 321
container
Mounting Elements

• Diameter: 30 to 70 mm Special gripper with permanent magnet for safe handling
• Holding force: 35 to 290 N of magnetic workpieces such as perforated metal sheets.
Vacuum Generators

container
Needle Grippers
Needle Grippers SNGi-AE 326
container
Valve Technology

• Needle diameter: 0.8 mm or 1.2 mm Electrical needle gripper in compact, maintenance friendly
• No. of needles: 10 design with automatic, continuously adjustable stroke
• Needle stroke: 3 mm to 20 mm (variable) and IO-Link interface for handling materials that are diffi- Switches and Monitoring
cult to grip using vacuum such as composite textiles, etc.

Needle Grippers SNG-AP 330
Filters and Connections

• Needle diameter: 0.8 mm or 1.2 mm Pneumatic needle gripper in compact, maintenance-
• No. of needles: 10 friendly design with manual, continuously adjustable
• Needle stroke: 3 mm to 20 mm (variable) stroke for handling materials that are difficult to grip
using vacuum such as composite textiles, etc.
Services
Needle Grippers SNG-V 334

• Needle diameter: 1.2 mm Needle gripper with intersecting needles and manual, Contact
• Number of needles: 10 continuously adjustable stroke for materials that are
• Needle stroke: 0 mm to 7 mm (variable) difficult to grip like composite textiles and much more.
