Compact Ejectors
Compact Ejectors SCPS / SCPSi
PA01019111_inh_EN.pdf Suction rate from 16 l/min to 67 l/min PA01019111_inh_EN.pdf

container
Schmalz - The Company Suitable for Industry Specific Applications

container
Applications

Vacuum Knowledge • Compact ejector for handling of airtight and slightly porous
workpieces
• Generation and monitoring of vacuum in automated systems

Vacuum Suction Cups • Use in robotic handling applications and on linear axes
• Pick-and-place applications with extremely short cycle times
• For systems that require highly dynamic gripping of workpieces
and where space is limited
Special Grippers • Typically for use in fully-automated small parts handling
applications

Vacuum Grip- ping Systems Compact ejectors SCPS / SCPSi Design
container

• Basic module made of high-strength plastic
Mounting Elements • Display screen or LED bar display (1)

• Keyboard (2) makes it easy to set the system parameters
• Electrical connection via standard M12 plug (3)
Vacuum Generators • Integrated pneumatic valves for switching functions NO or NC
• Screw (4) to adjust blow off for lightweight pieces
• Pneumatic connections (G1/8") with protective screens (5)

Valve Technology System design compact ejectors SCPS / SCPSi • Open silencer (6)
• Can optionally be mounted using DIN rails (7)

container Our Highlights... Your Benefits...
Switches and Monitoring • Efficient eco nozzle techno- >Higher suction rate with

logy
minimal compressed air
consumption
Filters and Connections • Integrated air saving function >Reduction of compressed air
consumption by up to 80 %
• IO-Link device for communi-
cating with an existing field- >Simple and quick installation,
device and process parameters
bus via IO-Link master can be transferred
Services • Brightly-lit display screen or >Highly visible display of impor-
LED bar display
tant vacuum parameters
• Large operating elements and >Easy and time-saving manual
an intuitive user menu adjustments on the ejector
Centralized vacuum generation by means of compact ejector SCPSi
Contact • Compact size, made of >Compact and durable unit;
can be mounted directly on
extremely durable plastic
the handling system
• Automatic blow off function >One less signal output is
Index of Products required per ejector

536 www.schmalz.com/scps
