R6PS Series

REGENAIR Regenerative Blowers
®

Model R6PS3110M (staged)
HigH Pressure Models Max. pressure – 170 inH O (60 Hz),145 inH O (50 Hz)
2
2
Max. vacuum – 130 inH O (60 Hz),110 inH O (50 Hz)
2 2
Max. air flow – 280 CFM (60 Hz), 230 CFM (50 Hz)
PRODUCT FEATURES
• Rugged construction, low maintenance
• Oilless operation
• UL and CSA approved motor with permanently
sealed ball bearings
• Aluminum impeller; cast iron cover and housing
• Includes muffler AJ121F
• Smaller and less costly than two motor-mounted units

RECOMMENDED ACCESSORIES
• Pressure gauge AE133A
• Inlet filter AJ126F (pressure)
• Vacuum gauge AE134
• Inline filter AJ151H (vacuum)
• Relief valve AG258
• Liquid separator RMS300 (vacuum)

Product Dimensions (inches, mm)

Note: Unit must be mounted with shaft horizontal.

TOP VIEW 2" Pipe
Outlet

Inlet Inlet 4.75 Approx
120,65
Outlet Outlet

29.50 Approx
749,30
8.29 Approx 6.61 Approx
210,57 167,89 2" Pipe 16.75
Outlet 425,45

2 x 18.21
462,53
4 x 15.15
384,81

2 x 18.00
4,57
9.00 Cent
8.09 7.00 228,60
205,49 177,80 4 x .56 Thru
14,22
23.19
589,03
®
46 Gast Regenair Regenerative Blowers www.gastmfg.com
