FEMALE-FEMALE COUPLINGS
Low Pressure Female x Low Pressure Female
Catalog Female Female
Number L/P L/P A B Port
LPC2L4L 1/8" 1/4" 0.75" (19.1) 1.50" (38.1) 0.093" (2.4)
LPC2L6L 1/8" 3/8" 0.75" (19.1) 1.75" (44.5) 0.093" (2.4)
LPC2L8L 1/8" 1/2" 1.00" (25.4) 2.00" (50.8) 0.093" (2.4) A HEX
LPC4L6L 1/4" 3/8" 0.75" (19.1) 1.75" (44.5) 0.187" (4.7)
LPC4L8L 1/4" 1/2" 1.00" (25.4) 2.00" (50.8) 0.187" (4.7)
LPC6L8L 3/8" 1/2" 1.00" (25.4) 2.00" (50.8) 0.312" (7.9) B

Low Pressure Female x High Pressure Female
Catalog Female Female
Number L/P H/P A B Port
LPC2L4H 1/8" 1/4" 0.75" (19.1) 1.50" (38.1) 0.093" (2.4)
LPC2L6H 1/8" 3/8" 1.00" (25.4) 2.00" (50.8) 0.093" (2.4)
LPC2L9H 1/8" 9/16" 1.38" (35.1) 2.25" (57.2) 0.093" (2.4) A HEX
LPC4L4H 1/4" 1/4" 0.75" (19.1) 1.50" (38.1) 0.093" (2.4)
LPC4L6H 1/4" 3/8" 1.00" (25.4) 1.75" (44.5) 0.125" (3.2)
LPC4L9H 1/4" 9/16" 1.38" (35.1) 2.25" (57.2) 0.187" (4.7) B
LPC6L4H 3/8" 1/4" 0.75" (19.1) 1.50" (38.1) 0.093" (2.4)
LPC6L6H 3/8" 3/8" 1.00" (25.4) 1.75" (44.5) 0.125" (3.2)
LPC6L9H 3/8" 9/16" 1.38" (35.1) 2.25" (57.2) 0.187" (4.7)
LPC8L4H 1/2" 1/4" 1.00" (25.4) 1.62" (41.1) 0.093" (2.4)
LPC8L6H 1/2" 3/8" 1.38" (35.1) 2.00" (50.8) 0.125" (3.2)
LPC8L9H 1/2" 9/16" 1.38" (35.1) 2.25" (57.2) 0.187" (4.7)

Low Pressure Female x Medium Pressure Female
Catalog Female Female
Number L/P M/P A B Port
LPC2L4M 1/8" 1/4" 0.75" (19.1) 1.50" (38.1) 0.093" (2.4)
LPC2L6M 1/8" 3/8" 1.00" (25.4) 1.50" (38.1) 0.093" (2.4)
LPC2L9M 1/8" 9/16" 1.00" (25.4) 2.00" (50.8) 0.093" (2.4)
LPC4L4M 1/4" 1/4" 0.75" (19.1) 1.50" (38.1) 0.103" (2.6) A HEX
LPC4L6M 1/4" 3/8" 0.75" (19.1) 1.75" (44.5) 0.203" (5.2)
LPC4L9M 1/4" 9/16" 1.00" (25.4) 2.00" (50.8) 0.187" (4.7)
B
LPC6L4M 3/8" 1/4" 0.75" (19.1) 1.50" (38.1) 0.103" (2.6)
LPC6L6M 3/8" 3/8" 0.75" (19.1) 1.75" (44.5) 0.203" (5.2)
LPC6L9M 3/8" 9/16" 1.00" (25.4) 2.00" (50.8) 0.312" (7.9)
LPC6L12M 3/8" 3/4" 1.38" (35.1) 2.50" (63.5) 0.312" (7.9)
LPC8L4M 1/2" 1/4" 0.75" (19.1) 2.00" (50.8) 0.103" (2.6)
LPC8L6M 1/2" 3/8" 1.00" (25.4) 2.00" (50.8) 0.203" (5.2)
LPC8L9M 1/2" 9/16" 1.00" (25.4) 2.00" (50.8) 0.359" (9.1)
LPC8L12M 1/2" 3/4" 1.38" (35.1) 2.50" (63.5) 0.437" (11.1)

NOTE: See page ACC-1 to determine maximum allowable working pressure (MAWP)

All dimensions are for reference only and are subject to change.
ACC-09 Dimensions in parentheses are millimeters (mm).
Page ACC-11
