Catalog 0980 OSP-P Pneumatic Rodless Cylinders and Linear Guides
Overview Linear Guides
��� Linear Guides

����� SLIDeLINe
The cost-effective plain bearing guide for medium loads.
������ Active/ Passive Brake optional.

���� Piston diameters 16 – 80 mm

Adaptive modular system
B The Origa system plus – OSP –
provides a comprehensive range of POWeRSLIDe
linear guides for the pneumatic and The roller guide for heavy loads
electric linear drives. and hard application conditions
Piston diameters 16 – 50 mm
Advantages:
• Takes high loads and forces
• High precision
• Smooth operation
• Can be retrofitted
• Can be installed in any position PROLINe
The compact aluminum roller guide for high loads
and velocities.
Active/ Passive Brake optional.
Piston diameters 16 – 50 mm

Rodless Pneumatic Cylinder
Series OSP - P

Piston diameters 10 – 80 mm StARLINe
Recirculating ball bearing guide for
See page: very high loads and precision
B7 (Standard) Piston diameters 16 – 50 mm

KF GUIDe
Recirculating ball bearing guide for
highest loads and precision.
Correspond to FESTO dimensions (Type DGPL-KF)
Piston diameters 16 – 50 mm

HD HeAVY DUtY GUIDe
The ball bushing guide for the heavy loads
and greatest accuracy.
Piston diameters 25 – 50 mm

B40 Parker Hannifin Corporation
Parker-Origa
ORIGA Glendale Heights, Illinois
www.parker.com/pneu/rodless
