759-841

Interface Configuration App 3

227

3

Interface Configuration App
DIP Switch Alternative Description
WAGO Interface Configuration App (Android)
WAGO's Interface Configuration App brings the power of a PC-based
configuration software to mobile end-user devices. WAGO's 857 Series Download from Google Play
signal conditioner's input and output parameters can be configured via finger
swipe on an Android-based smartphone or tablet. Furthermore, both configura-
tion data and actual measured values can be easily displayed.
®
WAGO's 750-921 Bluetooth Adapter communicates between a smartphone
and signal conditioner.

Device Information Input Parameter Output Parameter Digital Output Actual Value

The following devices are already supported:
857-401: Isolation Amplifi er 2857-401: Universal Isolation Amplifi er
857-500: Frequency Signal Conditioner 2857-533: RTD Threshold Value Switch
857-531: Threshold Value Switch 2857-534: TC Threshold Value Switch
857-550: Current Signal Conditioner 2857-550: Current Signal Conditioner
857-552: Rogowski Signal Conditioner
857-801: Temperature Signal Conditioner for Pt Sensors
857-809: Potiposition Signal Conditioner
857-811: Temperature Signal Conditioner for TC Sensors
857-819: Millivolt Signal Conditioner

®
JUMPFLEX -ToGo Download from
Google Play
