Application Examples

WAGO-I/O-SYSTEM 753 WAGO Interface Cables WAGO Interface Modules

WAGO-753 T8ES, 2 m long T16ES
753-430 (x2), 16 DI
706-7753/301-200 704-2004

WAGO-I/O-SYSTEM 753 WAGO Interface Cables WAGO Interface Modules
I/O Modules Item No. pcs Type pcs
753-430 (x1) 8 DI 706-7753/300-XXX 1 T8ES 1 7
753-430 (x2) 16 DI 706-7753/301-XXX 1 T16ES 1
DI
753-431 (x1) 8 DI 706-7753/300-XXX 1 T8ES 1
753-431 (x2) 16 DI 706-7753/301-XXX 1 T16ES 1
T8ES/T8S
8 DO
DO 753-530 (x1) 16 DO 706-7753/300-XXX 1 1 T16ES/T16S 1 1
706-7753/301-XXX
753-530 (x2)
Overview over cables and interface modules see page 389

WAGO-I/O-SYSTEM 750 WAGO Interface Cables WAGO Interface Modules

I/O Modules Item No. pcs Type pcs
DI 750-1400 16 DI 706-3057/300-XXX 1 T16ES 1
DO 750-1500 16 DO 706-3057/300-XXX 1 T16ES 1

DI/DO 750-1502 8 DI/8 DO 706-7753/302-XXX 1 1 T8ES/T8S 1/1

1
T16ES
750-1502
8 DI/8 DO
706-3057/300-XXX
Overview over cables and interface modules see page 389
