Parker Pneumatic Stainless Steel FRLs

Dimensions (mm) - 1/2"

Filters Regulators
Coalescing Filters

B A
B

A

C1
C
E1 E

D D

PR11 PR10

A A1 B C D E F A B C C1 D E E1
60mm 64mm 44mm 14mm 127mm 141mm 54mm 60mm 62mm 91mm 119mm 35mm 126mm 154mm

Filter/Regulators Lubricators

Optional Sight Gauge
A1 Optional Sight Gauge
A1
A
A

C1 C

E1 E

D D

1/8” 1/8”
Female Distance Required Distance Required
Female
Thread B Dia. F To Remove All Thread B Dia. F To Remove All
Bowls Regardless Bowls Regardless
of Drain Option of Drain Option
PB12 PB11
A A1 B C C1 D E E1 F A A1 B C D E F
60mm 64mm 44mm 91mm 119mm 127mm 218mm 246mm 54mm 60mm 64mm 44mm 46mm 127mm 173mm 89mm
