Combining 1- and 2-conductor terminal blocks, also with different housing colors and pin spacing. Inserting solid conductors via push-in termination.
1 = 10/10.16 mm pin spacing 3 = 3.81 mm pin spacing 3 = 3.81 mm pin spacing
2 = 5/5.08 mm pin spacing 4 = 3.96/4 mm pin spacing 4 = 3.96/4 mm pin spacing

235 Series

Inserting/removing fine-stranded conductor via
push-button.

Inserting/removing ferruled, fine-stranded conductor via
push-button.

Formation of Groups

Combining 1 and 2-wire terminal blocks and pin spacing. Application example: power supply terminal strip.

fine-stranded, fine-stranded,
fine-stranded, with ferrules with pin terminal
tip-bonded (gastight crimped) (gastight crimped)
