Hose
A PTFE Heat ShrinkableTubing

Series 4:1 HS4TFI

Features

ƒ Virgin Polytetrafluoroethylene resin
ƒ 4:1 Shrink Ratio
Tubing Fluoropolymer ƒ Chemically inert
ƒ Lowest coefficient of friction
B ƒ Superior dielectric strength
ƒ Exceptional heat resistance
ƒ Self extinguishing
ƒ Non-wetting

Coiled Air Hose & Fittings Applications/Markets Certifications

ƒ AMS-DTL-23053/12A, Class 5
ƒ Electrical Insulation
ƒ ASTM D2902 Type I
C ƒ Protective Cover ƒ AMS 3584A
ƒ Rollers ƒ VW1, UL-83 (natural)
ƒ Bulb Protection ƒ FDA Compliant
ƒ USP Class VI Compliant

Transportation Order Information Colors

D Example: HS4TFI5/8-NT ƒ Natural, Opaque to translucent
HS4TFI5/8-NT – Heat Shrink ƒ Colors available as custom run, see color code table

HS4TFI5/8-NT – Shrink Ratio (4:1) When ordering coiled tubing in colors, the color code is
HS4TFI5/8-NT – PTFE always followed by TC; when ordering cut lengths, the color
code is followed by CC
HS4TFI5/8-NT – Wall Type (Industrial Wall)
HS4TFI5/8-NT – Heat Shrink Size in inches (5/8") i.e.,HS4TFI5/8-2TC i.e.,HS4TFI5/8-0CC48.0000
Fittings HS4TFI5/8-NT – Natural Color Code
HS4TFI5/8-NT – Bulk Tubing
E N Natural 5 Green
Black
Blue
Notes 0 1 Brown 6 7 Violet
ƒ Working Temperature: -500°F (260°C)
2 Red 8 Gray
ƒ Shrink Temperature: 662°F (350°C) for 10 minutes
AMS-DTL-23053/12A 3 4 Orange 9 White
ƒ For full recovery, expanded diameter should be 50%
Yellow
Tooling, Equipment & Accessories ƒ *Dielectric Strength: > 1,400 V/M, per ASTM D 149 short
larger than the diameter of the object to
be recovered over
term test of 10 MIL thickness (Volts/MIL)
packaging of 4-ft. straight lengths
F ƒ PTFE Fractional Heat Shrink tubing is available in stock
ƒ Minimum quantities may apply
ƒ Custom packaging, sizes, lengths and colors are quoted
upon request

General Technical

G For detailed ordering information, please consult price list or contact Parflex Division.
B-78 Parker Hannifin Corporation | Parflex Division | Ravenna, Ohio | parker.com/pfd
