Transmission Fittings
Transmission Fittings
Parker’s Transmission Fittings utilizes a specially designed slotted sleeve to help eliminate notch stress
related to over-torque. Ideal for pressure protected pneumatic transmission applications. Electroless
nickel plated bodies can be used with bio-diesel.
Product Features:
■ Brass Body
■ D.O.T. Approved with Staked in Tube Support
■ 3/16” & 5/32” Tube sizes
■ Slotted Sleeve
■ Nickel Plated Versions Available for Bio-diesel
Markets: Applications:
■ Heavy Duty Truck ■ Air Shift Transmissions
■ Seat Controls
■ Dash Controls
Specifications:
Pressure Range Up to 150 psi
Temperature Range -40˚ to 200˚F
Compatible Tubing:
■ SAE J844 Type A & B nylon tubing
Parker Hannifin Corporation | Fluid System Connectors | Otsego, MI F10
