Page 285 - Brass, Composite and Thermoplastic Fittings and Valves

Catalog 3501E

L
M Hose Barb Fittings

Beaded Hose Barb 45 Hex
Elbow to Metric Thread N
179HB-X-MIX D 0123 Barbed Adapter for Rubber Hose BSPT
PART HOSE METRIC HEX L M N D PART D C D1 F L L1 T WT.
NUMBER SIZE THREAD NO. MM BSPT MM MM MM MM MIN KG
179HB-12-MI18 3/4 M18 X 1.5 13/16 1.15 .78 1.16 .44 MM
0123 04 10 4 R1/8 6 10 34 22.5 3.3 .008
179HB-16-MI27 1 M27 X 2.0 1 1/16 1.51 .97 1.71 .71
0123 06 10 6 R1/8 8 10 34 22.5 5 .009
Note: Fluorocarbon o-ring is standard
0123 07 10 7 R1/8 9 10 34 22.5 5 .009
0123 07 13 7 R1/4 9 14 38.5 22.5 6 .018
0123 07 17 7 R3/8 9 17 39 22.5 6 .023
L
M 0123 10 10 10 R1/8 12.2 13 34 22.5 5 .014
Beaded Hose Barb 90° 0123 10 13 10 R1/4 12.2 14 38.5 22.5 7 .021
Elbow Tube to Male N 0123 10 17 10 R3/8 12.2 17 39 22.5 9.5 .023
Pipe 269HB D 0123 12 17 12 R3/8 14 17 46 29.5 11 .026
0123 13 13 13 R1/4 15 17 45.5 29.5 7 .027
PART I.D. HOSE PIPE L M N FLOW
NO. SIZE THREAD DIA. D 0123 13 17 13 R3/8 15 17 46 29.5 11 .027
269HB-6-6 3/8 3/8 1.19 .78 .88 .281 0123 13 21 13 R1/2 15 22 50.5 29.5 12 .047
269HB-8-4 1/2 1/4 1.16 .78 .99 .310 0123 16 17 16 R3/8 18.5 19 54.5 38 11 .040
269HB-8-6 1/2 3/8 1.16 .78 1.08 .406 0123 16 21 16 R1/2 18.5 22 59 38 14 .056
269HB-8-8 1/2 1/2 1.28 .78 1.25 .406 0123 16 27 16 R3/4 18.5 27 62 38 15 .082
269HB-10-4 5/8 1/4 1.13 .78 .99 .312 0123 19 17 19 R3/8 21.5 22 54.5 38 11 .046
269HB-10-6 5/8 3/8 1.16 .78 .99 .406 0123 19 21 19 R1/2 21.5 22 59 38 14 .058
269HB-10-8 5/8 1/2 1.28 .78 1.25 .501 0123 19 27 19 R3/4 21.5 27 62 38 18 .083
269HB-12-8 3/4 1/2 1.28 .78 1.25 .563 0123 25 27 25 R3/4 26.7 27 62 38 18 .083
269HB-12-12 3/4 3/4 1.33 .78 1.27 .625 0123 25 34 25 R1 27 36 65 38 24 .124
0123 32 34 32 R1 34.5 36 70 43 24 .144

L
C M
HEX
N
Beaded Hose Barb 45° D O.D.
Elbow Tube to Male
Pipe 279HB

PART I.D. NPTF C FLOW
NO. HOSE THREAD HEX L M N O.D. DIA.
SIZE D
279HB-16-12 1 3/4-14 1.12 1.38 .97 1.13 1.06 .720

Parker Hannifin Corporation | Fluid System Connectors | Otsego, MI I13
