Accessories 16 Compartment Large Scoop Box Positive pull-down catch keeps cover

■
Prime cold rolled steel outer shell
■
tightly closed to prevent part migration
■
High impact styrene insert
with 16 compartments
Durable gray powder coat finish
■
■ Scooped bottom compartments ■ Handle allows for easy transport
for easy part removal
■ Full piano hinge on cover
provides rigidity
DIMENSIONS (IN.)
PART NUMBER
WIDTH DEPTH HEIGHT
16-CB 18 12 3

24 Compartment Large Scoop Box
■ Prime cold rolled steel outer shell ■ Positive pull-down catch keeps cover
■ High impact styrene insert tightly closed to prevent part migration
with 24 compartments ■ Handle allows for easy transport
■ Scooped bottom compartments ■ Durable gray powder coat finish
for easy part removal
■ Full piano hinge on cover
provides rigidity
DIMENSIONS (IN.)
PART NUMBER
WIDTH DEPTH HEIGHT
24-CB 18 12 3

ADJ-CB

■ Prime cold rolled steel outer shell ■ Positive pull-down catch keeps cover
■ High impact styrene insert with 4 fixed tightly closed to prevent part migration
vertical compartments and 9 moveable ■ Durable gray powder coat finish
dividers adjustable on 1” centers
■ Full piano hinge on cover
provides rigidity
DIMENSIONS (IN.)
PART NUMBER COMPARTMENTS
WIDTH DEPTH HEIGHT
ADJ-CB 18 12 3 ADJUSTABLE

Easy Glide Slide Rack (Holds 4 16-CB or 24-CB per rack)

■ Sturdy construction using ■ Reinforced rack keeps boxes level
prime cold-rolled steel ■ Boxes can be easily removed
■ Each cradle holds up to 40 lbs for transport to work areas
■ Easy glide slides allow boxes to ■ Base and locking hinge are
move in and out smoothly available as accessories
■ Center braces on cradles ■ Durable gray powder coat finish
provide extra rigidity

DIMENSIONS (IN.)
PART NUMBER
WIDTH DEPTH HEIGHT
4CB-SR 20 15.75 15
