Catalog 3501E



            LSR-Stand
            ■   Sturdy all steel construction                                                                          Accessories
            ■   Raises units 15 inches off the floor
            ■   Legs attach easily using fasteners provided
            ■   Durable gray powder finish

                                         DIMENSIONS (IN.)
               PART NUMBER
                              WIDTH        DEPTH        HEIGHT
               LSR-STAND      20 5/8       16 1/4        15 5/8



            9 Drawer Cabinet
            ■   Prime cold rolled steel construction  ■   Each drawer includes 2 easy
            ■   High density drawer cabinet, easy to   label dividers, which are
               store large quantities of small parts  adjustable on 1” centers
            ■   Drawers feature interlocking   ■   Cabinets can be stacked
               design for superior strength      using mounting holes
            ■   Drawers have full width handles   ■   Durable gray powder coat finish
               and easy glide runners         ■   Ships fully assembled

                               DIMENSIONS (IN.)          DRAWER DIMENSIONS (IN.)
             PART NUMBER
                        WIDTH     DEPTH    HEIGHT    WIDTH    DEPTH     HEIGHT
               9-DC      17.25    11.625   10.875    5.375     11.25    2.75



            18 Drawer Cabinet
            ■   Prime cold rolled steel construction  ■   Each drawer includes 2 easy
            ■   High density drawer cabinet, easy to   label dividers, which are
               store large quantities of small parts  adjustable on 1” centers
            ■   Drawers feature interlocking   ■   Cabinets can be stacked
               design for superior strength      using mounting holes
            ■   Drawers have full width handles   ■   Durable gray powder coat finish
               and easy glide runners         ■   Ships fully assembled

                               DIMENSIONS (IN.)          DRAWER DIMENSIONS (IN.)
             PART NUMBER
                        WIDTH     DEPTH    HEIGHT    WIDTH    DEPTH     HEIGHT
               18-DC     17.25    11.625    21.25    5.375     11.25    2.75


            24 Opening Bin

            ■   All welded, prime cold rolled steel  ■   Modular with  most 12” deep bins and
            ■   Fully hemmed 1 1/8” bin fronts   drawer cabinets; mounting holes are
               to hold labels and retain parts   located at both the top and bottom
            ■   Roll-formed sides for increased   ■   Durable gray powder coat finish
               strength and stability         ■   Ships fully assembled
            ■   Ribbed and hemmed dividers
               provide added strength


                               DIMENSIONS (IN.)            BIN DIMENSIONS (IN.)
             PART NUMBER
                        WIDTH     DEPTH    HEIGHT    WIDTH    DEPTH     HEIGHT
             24B-CABINET  33.75    12      23.875    5.375    11.875     5.5









                       Parker Hannifin Corporation  |  Fluid System Connectors  |  Otsego, MI                 L13
