Catalog PDN1000-3US Actuator Products – Guided Cylinders
Parker Pneumatic P5L Series

Horizontal Load Capacity & Deflection with Oversized Shafting

• Oversized Composite w/ Chrome Plated or Dynamic loading is defined as a load which is affixed to the
Stainless Steel Rods actuator tooling plate during the extend or retract motion of
The graphs on the following two pages illustrate the maximum the actuator. Capacities are based on bearing and shafts only.
suggested side load at a given actuator stroke. The graphs Mounting bolts/hardware should be investigated per customer
include the weight of the carriage and are based on a bearing application.
life of 10 million cycles under a dynamic loading condition. For Note: The following variables commonly affect the bearing life
an equivalent static load capacity multiply the information in of a guided cylinder:
these graphs by 1.5. • Velocity
See the P5L options section of this catalog for more bearing • Vibration
selection information.
• Orientation
B • Environment (Dust, moisture, etc.)

P5L Base Slides
20mm Bore Size 25mm Bore Size
4800 6000
Guided Cylinders
Actuator Products
(1080) (1350)
0.5mm 0.2mm
1mm 0.5mm
3600
(810)
Oversized
Composite 4000
2400
Load, N (lb) (540) Load, N (lb) (900)
P5T
Series
0.1mm 2000 Oversized Composite
(450)
1200 0.05mm
P5L
Series
(270)
0
0 100 200 300 400 0 100 200 300 400 500
HB
(3.9) (7.9) (11.8) (15.7) (3.9) (7.9) (11.8) (15.7) (19.7)
Series
Stroke + d, mm (in) Stroke + d, mm (in)
32mm Bore Size 40mm Bore Size
9000 10000
(2025) (2250)
P5E
Series
0.1mm
0.2mm 0.5mm
0.3mm
7500
(1688)
6000
Load, N (lb)(1350) Oversized Composite Load, N (lb) (1125) Oversized Composite
5000
3000
(675)
2500
0.05mm (563)
0.03mm
0 0
0 200 400 600 0 200 400 600 800
(7.9) (15.7) (23.6) (7.9) (15.7) (23.6) (31.5)
Stroke + d, mm (in) Stroke + d, mm (in)
