Catalog PDN1000-3US Actuator Products – Guided Cylinders
Parker Pneumatic P5L Series

Vertical Eccentric Load Capacity

• Standard Composite w/ Chrome Plated or An eccentric load is defined as a load applied in the same
Stainless Steel Rods direction as the motion of the cylinder however, acting at some
• Oversized Composite w/ Chrome Plated or distance (eccentricity "h") from the center of the tooling plate.
Stainless Steel Rods Capacities are based on bearing and shafts only. Mounting
bolts/hardware should be investigated per customer
• Recirculating Ball Bearings w/ Carbon or application.
Stainless Steel Rods
• Self Aligning Ball Bearings w/ Carbon or Note: The following variables commonly affect the bearing life
of a guided cylinder:
Stainless Steel Rods
• Velocity
The graphs on the following two pages illustrate the maximum
suggested eccentric load based on a stroke of 100mm • Vibration
(4 inches). • Orientation
• Environment (Dust, moisture, etc.)
B P5L Thrust Slides
20mm Bore Size 25mm Bore Size 32mm Bore Size
1600 1600 2400
(360) (360) (540)
1200 1200 1800
(270) (270) (405)
Load, N (lb) (180) Load, N (lb) (180) Load, N (lb) 1200
800
800
(270)
Guided Cylinders
Actuator Products
400 400 600
(90) (90) (135)
0 0 0
0 120 240 360 0 120 240 360 480 0 200 400 600
(4.7) (9.4) (14.2) (4.7) (9.4) (14.2) (18.9) (7.9) (15.7) (23.6)
Eccentricity, mm (in) Eccentricity, mm (in) Eccentricity, mm (in)
P5T
Series
40mm Bore Size 50mm Bore Size 63mm Bore Size
2800 4000 6000
(630) (900) (1350)
P5L
Series
2100 3000
(473) (675) (900)
4000
Load, N (lb) (315) Load, N (lb) 2000 Load, N (lb)
1400
(450)
HB
2000
Series
700 1000 (450)
(158) (225)
0 0 0
0 200 400 600 0 200 400 600 0 200 400 600
( )7.9 ( )15.7 ( )23.6 (7.9) (15.7) (23.6) (7.9) (15.7) (23.6)
P5E
Series
Eccentricity, mm (in) Eccentricity, mm (in) Eccentricity, mm (in)
80mm Bore Size 100mm Bore Size
9000 12000
(2025) (2700)
9000
6000 (2025)
(1350)
Load, N (lb) Load, N (lb) (1350) LEGEND
6000
Standard Composite
3000
(675) 3000 Oversized Composite
(675) Recirculating Ball Bearing
Self Aligning Ball Bearing
0 0
0 200 400 600 0 200 400 600
(7.9) (15.7) (23.6) (7.9) (15.7) (23.6)
Eccentricity, mm (in) Eccentricity, mm (in)
B190 Parker Hannifin Corporation
