Catalog PDN1000-3US Actuator Products – Guided Cylinders
Parker Pneumatic P5L Series

Horizontal Load Capacity & Deflection with Oversized Shafting

• Oversized Composite w/ Chrome Plated or Dynamic loading is defined as a load which is affixed to the
Stainless Steel Rods actuator tooling plate during the extend or retract motion of
The graphs on the following two pages illustrate the maximum the actuator. Capacities are based on bearing and shafts only.
suggested side load at a given actuator stroke and distance Mounting bolts/hardware should be investigated per customer
(d) from the face of the tooling plate. The graphs include the application.
weight of the support rods and tooling plate and are based Note: The following variables commonly affect the bearing life
on a bearing life of 10 million cycles under a dynamic loading of a guided cylinder:
condition. For an equivalent static load capacity multiply the • Velocity
information in these graphs by 1.5.
• Vibration
See the P5L options section of this catalog for more bearing
selection information. • Orientation
B • Environment (Dust, moisture, etc.)

P5L Reach Slides

20mm Bore Size 25mm Bore Size
1200 1500
Guided Cylinders
(270) (338) 0.5mm
Actuator Products
1mm 2mm
3mm
1200
900 (270)
(202) Oversized Composite
Oversized Composite 900
Load, N (lb) (135) Load, N (lb) (202)
P5T
Series
600
600
(135)
300
P5L
Series
(67) 0.2mm 300
(67)
0.1mm
0 0
0 60 120 180 240 300 0 120 240 360 480
HB
(2.4) (4.7) (7.1) (9.4) (11.8) (4.7) (9.4) (14.2) (18.9)
Series
Stroke + d, mm (in) Stroke + d, mm (in)
32mm Bore Size 40mm Bore Size
2400 2400
(540) (540)
P5E
Series
0.5mm 0.5mm
1mm 1mm
1800 1800
(405) (405)
Oversized Composite
Load, N (lb) (270) Oversized Composite Load, N (lb) 1200
1200
(270)
600 600
(135) (135)
0.1mm 0.1mm

0 0
0 200 400 600 0 200 400 600
(7.9) (15.7) (23.6) (7.9) (15.7) (23.6)
Stroke + d, mm (in) Stroke + d, mm (in)
