Catalog PDN1000-3US Actuator Products – Guided Cylinders
Parker Pneumatic P5E Series

Maximum Load Capacity with Standard Shaft

The following curves are based on 10 million cycles at a
speed of 0.20 m/s (40 fpm). Higher dynamic loads will reduce Distance (d)
cycle life. For static conditions, multiply the information in the Load
graphs by 1.5.
EXAMPLE: A P5E with 40mm bore, composite bushings and
a “stroke+d” of 400mm will have a load capacity of 48N.
Deflection

B 32mm Bore Size 40mm Bore Size

200 300
(45) (67) Standard Composite
Standard Composite
250
150 (56) Ball Bearing
Ball
(34) Bearing (45)
200
Load, N (lb) 100 4.96 mm Load, N (lb) (34) 2.32 mm
150
(22)
100
Guided Cylinders
Actuator Products
50 (22) .18 mm .42 mm
(11) .32 mm .79 mm 1.98 mm 50 .99 mm
.13 mm (11) .08 mm
0 0
0 100 200 300 400 500 0 100 200 300 400 500
(3.9) (7.9) (11.8) (15.7) (19.7) (3.9) (7.9) (11.8) (15.7) (19.7)
Stroke + d, mm (inch) Stroke + d, mm (inch)
