Catalog PDN1000-3US Shock Absorbers
Parker Pneumatic Shocks

Shock Absorbers

The use of one piece / closed end bodies and inner pressure
chambers provides extremely strong construction, which can
withstand much higher internal pressures and overload forces
without mechanical damage.
The closed end / one piece bodies and inner pressure
chambers, reduces the chance of sudden failure, or machine
damage in the event of an overload.

B

Shock Absorbers Actuator Products

Specifications Shock Absorbers
Oil type Materials Mechanical stop Lock nut
Steel body: Black oxide finish.
MC 9 - MC 75 Silicone Included
Piston rod: Hardened stainless steel.
Steel body: Black oxide finish. Must be provided 0.02 to 0.04 inch
MC 150 - MC 600 Silicone Piston rod: Hardened stainless steel. (0.5 to 1 mm) before end of stroke. Included
Rolling seal: EPDM*
Steel body: Black oxide finish. Integral mechanical stop built into front of
SC 190 - SC 925 #5 Piston rod: Hardened stainless steel. units. Included
Steel body: Black oxide finish. Integral mechanical stop built into front of
SC 300 - SC 650 #5 Included
Piston rod: Hardened stainless steel. units.
MA 35: #5 Steel body: Black oxide finish. Adjustment screw for optimum
MA 35 - MA 900 MA 150: Silicone Piston rod: Hardened stainless steel. deceleration. Included
MA 225, 600, 900: ATF
MC 33 - MC 64 ATF Steel body: Black oxide finish. Included
Self-Compensating Piston rod: Hardened, high tensile
steel, chrome plated.
MC 33 - MC 64 Rod end button: Hardened steel with Turn front stop collar or rear adjuster
Adjustable ATF black oxide finish. against the scale marked 0 to 9 for Included
Return spring: Zinc plated optimum deceleration
Steel body: Black oxide finish.
Piston rod: Hardened, high tensile Must be provided .09 inch (2.3 mm) before
1-1/2" Bore Series American 46 steel, chrome plated. end of stroke.
Return spring: Zinc plated
CA 2 - CA 4 Steel body: Black oxide finish. Must be provided .09 inch (2.3 mm) before
Self-Compensating ATF Piston rod: Hardened, high tensile end of stroke.
A 2 - A 3 ATF steel, chrome plated. Must be provided .09 inch (2.3 mm) before
Adjustable Return spring: Zinc plated end of stroke.
* Seal not compatible with petroleum based fluids) If unit to be used in contact with such fluids specify neoprene rolling seal. Consider the SC2 Series as an alternative.
