X-COM @-SYSTEM S
®
2 1-Conductor Female Plugs for Ex nA Applications
146 2022 Series

0.25 - 2.5 (4) mm² 1 AWG 22 - 12
630 V 2
I N 20 A
Module width 5.2 mm / 0.205 in
L 10 - 12 mm / 0.43 in 3

Pole
1
Each female plug is supplied with a locking lever.
1 Conductor sizes: 0.25 mm² – 4 mm² “s + f-st”;
Push-in conductor sizes: 0.75 mm² – 4 mm² “s”
and 0.75 mm² – 2.5 mm²
“insulated ferrule, 12 mm”
2 630 V = rated voltage for Ex nA applications
3 (see Section 14)
4 Strip length, see packaging or instructions.
Pack. Accessories
Pole No. Item No.
Unit Appropriate marking systems:
1-conductor female plug with shorter locking lever, WMB/Marking strips/WMB Inline
for insertion into carrier terminal blocks, with coding fin-
gers, gray Insulation stop,
According to EN 61984, connectors without current inter- 5 pcs/strip,
rupting capacity shall not be mated and unmated when 0.25 - 0.5 mm²
live or under load. light gray 2002-171 200 (8x25)
2 2022-102/999-953 200 Insulation stop,
3 2022-103/999-953 100 5 pcs/strip,
4 2022-104/999-953 100 0.75 - 1 mm²
5 2022-105/999-953 50 dark gray 2002-172 200 (8x25)
6 2022-106/999-953 50 Protective warning marker,
7 2022-107/999-953 50 with high-voltage symbol, black,
8 2022-108/999-953 50 for 5 terminal blocks
yellow 2002-115 100 (4x25)
Carrier with 6 coding pins,
for coding female plugs
orange 2022-100 100 (4x25) To code a female plug, remove the desired coding finger
using a suitable tool.
Strain relief plate, gray
35 mm width 734-326 100 (4x25)
6 mm wide 734-327 100 (4x25)
12.5 mm width 734-328 100 (4x25)
25 mm wide 734-329 100 (4x25)
55 mm width 734-430 50 (2x25)
75 mm width 734-431 50 (2x25)
WMB Multi marking system,
10 strips with 10 markers per card,
stretchable 5 - 5.2 mm
plain 793-5501 5
WMB Inline, plain,
stretchable 5 - 5.2 mm,
1,500 WMB markers, 5 mm, on roll
white 2009-115 1
Marking strip, plain,
11 mm wide,
50 m roll
L 26,8 white 2009-110 1 Insert a 2022-100 coding pin into the corresponding loca-
>5,2 < <___ 22,4 ___> tion of the carrier terminal block.
<____ 26,6 ____> <________ 40,5 ________>

L = pole no. x module width
Dimensions in mm
