Jumpers with Safety Lid for
Longitudinal Switching Disconnect Terminal Blocks 5
Series 282 235
5
Jumper with safety lid Jumper with safety lid
– Jumper in pre-latching position Longitudinal switching disconnect terminal blocks with
inserted jumper, including safety lid
Jumper with safety lid Jumper with safety lid
– Jumper with raised safety lid – Removing jumper via safety lid
