Circuit Configuration Examples
Double-Deck Diode and LED Terminal Blocks 5
283

Recovery diodes can be created using the following Lamp test circuits can be created using the following
terminal blocks: terminal blocks:
281-633/281-410 or 281-636/281-487 or
281-633/281-411 281-636/281-488

1 Strip length, see packaging or instructions.
281 Series Accessories 5
Appropriate marking system:
WMB (see Section 13)
End and intermediate plate, 2.5 mm thick
orange 281-341 100 (4x25)
gray 281-340 100 (4x25)
Insulation stop,
5 pcs/strip,
0.08 - 0.2 mm² “s” (0.14 mm² “f-st”)
white 281-470 200 (8x25)
Lamp test circuits can be created using the following Collective fault signals can be created using the fol- Insulation stop,
terminal blocks: lowing terminal blocks: 5 pcs/strip,
281-635/281-492 or 281-635/281-489 or
281-635/281-491 281-635/281-490 0.25 - 0.5 mm²
light gray 281-471 200 (8x25)
Insulation stop,
5 pcs/strip,
0.25 - 1.5 mm²
dark gray 281-472 200 (8x25)
Comb-style jumper bar, insulated,
Double-deck diode terminal blocks I N = I N terminal block
have been specially developed for custom diode circuits, 2-way 281-482 100 (4x25)
such as lamp test and collective fault signal circuits.
Using LED terminal blocks, monitoring units can be 3-way 281-483 100 (4x25)
designed, e.g., for control and operating circuits. 5-way 281-485 100 (4x25)
The terminal blocks provide high-density wiring, while 10-way 281-490 50 (2x25)
maintaining a width of only 6 mm.
Alternate comb-style jumper bar,
insulated,
I N = I N terminal block
2-way 281-492 100 (4x25)
Operating tool, of insulating material
Circuit-related voltage indications can be created 2-way 280-432 1
using the following terminal blocks: 3-way 280-433 1
281-634/281-434 or
281-634/281-413 5-way 281-440 1
Wire commoning chain, 50 connections,
insulated, I N 8 A
black 210-103 1
Wire commoning chain, 50 connections,
insulated, I N 8 A
blue 210-123 1
