6 Fuse Plugs and
Pluggable Diode and LED Modules
332

Fuse plugs Diode modules LED modules

Pack. Pack. Pack.
Item No. Item No. Item No.
Unit Unit Unit
Fuse plug, 5 mm wide, Diode module, 5 mm wide, LED module, 5 mm wide,
with soldered miniature fuse with 1N4007 diode with red LED

250 mA FF 280-850 100 280-801/281-411 100 24 VDC 280-801/281-413 100
500 mA FF 280-852 100 48 VDC 280-801/281-414 100
1 A FF 280-854 100
2 A FF 280-856 100
Fuse plug, 5 mm wide, Diode module, 5 mm wide, LED module, 5 mm wide,
with soldered miniature fuse with recovery diode 1N4007, with red LED
with indicator lamp, additional LED
additionally LED,
15 – 30 VDC 24 VDC 280-801/281-420 100 24 V AC/DC 280-801/281-415 100
Leakage current in case of blown fuse: 5 – 20 mA 48 VDC 280-801/281-421 100 48 V AC/DC 280-801/281-416 100
250 mA FF 280-850/281-413 100
500 mA FF 280-852/281-413 100
1 A FF 280-854/281-413 100 Neon indicator module, 5 mm wide
2 A FF 280-856/281-413 100

Fuse plug with pull-tab, 6 mm wide, 120 V AC/DC 280-801/281-418 100
for miniature fuses 5 x 20 mm 230 V AC/DC 280-801/281-417 100
and 5 x 25 mm

281-511 50
with hole for one LED (for self-assembly)
281-512 50

Fuse plug with pull-tab, 6 mm wide,
for miniature fuses 5 x 20 mm
and 5 x 25 mm,
with LED inicator
Leakage current in case of blown fuse: 5 – 20 mA
Use in both switching directions
24 V AC/DC 281-512/281-501 50

Fuse plug with pull-tab, 6 mm wide,
for miniature fuses 5 x 20 mm
and 5 x 25 mm
with neon lamp
Leakage current in case of blown fuse:
Neon lamp < 0.4mA
120 V AC/DC 281-512/281-418 50
230 V AC/DC 281-512/281-417 50

Certification organizations can be found in the overview on pages 622 and 623.
