– Description and Handling – 8
Fixing 395
Terminal strip with fixing flanges, Terminal strip with snap-in mounting feet, Terminal strip with snap-in mounting feet,
screw mount. mounting in holes. mounting onto special aluminum rail.
8
Testing
Testing with test plug module assembly Testing with test plug module – fully clamped by
®
– touch contact. CAGE CLAMP .
fine-stranded, fine-stranded,
fine-stranded, with ferrule 1 with pin terminal
tip-bonded (gastight crimped) (gastight crimped)
1 When using ferrules, the max. conductor cross section accommodated is one size smaller than max. rating of terminal block.
