Busbar Carriers
790 Series 13
515
Busbar carrier

Snapping the busbar carrier onto DIN 35 rail. Placing the busbar in the carrier holder.

Pack.
Item No.
Unit
Busbar carrier, insulated,
for busbars Cu 10 mm x 3 mm,
no contact to DIN rail
790-400 20

Snapping the fixing bracket into position. Release the fixing braket by pushing the operating tool
down ! and then forward ".

36,25
24 13

70 8

104,3
Dimensions in mm
