GSX Series Integrated Motor/Actuator

System Configuration

GSX Series actuators include an integrated brushless servo systems. For food and beverage packaging, to multi-axis
motor. The unique design gives users a variety of feedback turning centers, to aircraft assembly, the GSX Series units
configuration options so GSX units can be powered by almost offers incredible performance and durability.
any brushless motor amplifier on the market.
The schematic below shows typical connections for a single GSX Series
This flexibility means GSX actuators can be incorporated into axis system with actuator and servo amplifier.
today’s high performance single and multi-axis motion control

Typical Servo
Amplifier

I/O Connections
To line
power

Motor and Power connections

Motor Power Cable

Brake Cable (if needed) Feedback Connections

Motor Feedback Cable
