Page 181 - Parker - Republic/Manatrol (Hydraulic and Pneumatic Control Valves)

Catalog HY14-3000/US Pressure Control Valves
Technical Information Series 665

Performance Curves

Factory Pressure Dash Range Factory Pressure
Setting PSI Flow Capacity No. PSI Setting PSI Flow Capacity
3200 3100 3200
2600 3000 12 to 2600 3000
2800 2000 2800
2200 2800 11 2750 2200 2800
to
2600
2600
2400 1500 2400
1750 2200 10 2100 1750 2200
2050
to
2050
1900 1400 1900
1000 1300 9 1500 1000 1300
1200
1200
to
1100 800 1100
1000 1020 1000
850 950 8 to 850 950
900 630 900
825 850 825
750 800 7 to 750 800
775 630 775
640 650 640
550 610 6 to 550 610
580 430 580
360 420 5 450 360 420
400
to
400
380 235 380
200 230 4 250 200 230
220
to
220
210 115 210
120 125 120
90 110 3 to 90 110
100 40 100
50 50 50
35 45 2 10 35 45
to
40
40
E 10 22 1 15 10 22
18
to
18
40
40
4
1 2 3 5 10 20 50 100 200 500 0 2 4 6 8 10 12 14 16 18 20
Rate of Flow SCFM 1/2", 3/4" Rate of Flow GPM
1/8", 1/4", 3/8"
Examples
Pneumatic: Hydraulic:
Establish cracking pressure setting of 1/2" valve for Find amount of pressure increase above 24.8 Bar
flow of 70 SCFM at 27.6 Bar (400 PSI) pressure: (360 PSI) cracking pressure when flow through
1. Project 70 SCFM on vertical scale. 3/4" valve is increased to 54 LPM (14 GPM):
2. Project 27.6 Bar (400 PSI) scale horizontally inter- 1. From 360 on vertical pressure scale, follow
sectiong 1. 3/4" curve until it intersects with the vertical line
3. Project line parallel to curves back to vertical line 1. representing 54 LPM (14 GPM).
4. Read cracking pressure setting: 24.8 Bar (360 PSI). 2. Project intersecting point horizontally and read
pressure, i.e., 29 Bar (420 PSI).
3. Accumulated Pressure:
420 minus 360 = 4.1 Bar (60 PSI).
