Catalog HY14-3000/US Accessories
Technical Information Series 910

Ordering Information

910 – D 2 B C

Hand Size Materials O-Ring Discharge Design
Pump and Port Series
Type Location

Code Description
D Aluminum Alloy
Code Description Code Description
6 IST* port
B Both Sides*
8 IST* port Code Description
* IST, military straight thread
port, SAE compatible. 2 Nitrile

Weight: 2.3 kg (5 lbs.)

Dimensions H
Inch equivalents for millimeter dimensions are shown in (**) G

Discharge Ports (both)
IST 6 or IST 8

Inlet Porting
IST 6 or IST 8
181.4 Left
(7.14) Side
96.8 Port
(3.81) Right Side
Port

9.7 71.4
(.38) (2.81)
52.3
(2.06)
28.4
33° 31° (1.12)
35.1
508 / (20.0) 69.9 65.8 66.8 36.6 (1.38)
69.9
Handle Extension (2.75) (2.59) (2.63) (1.44) (2.75)
115.8 41.4
(4.56) Ø7.1 (.281) (1.63) 82.6
thru 4 places (3.25)

3000-G1.p65, dd
G3 Parker Hannifin Corporation
Hydraulic Valve Division
Elyria, Ohio, USA
