PVC NEXAQUA

PVC Water Hose

Series 160 (Opaque Green Cover) /
Series 161 (Green Tint Cover)

Series 160/161 is silicone-free, commercial grade PVC water hose. The cover
is resistant to abrasion, ultraviolet light and weathering.
Tube: Black PVC
Reinforcement: Multiple textile plies
Cover: Opaque green or green tint PVC
Temp. Range: +25°F to +150°F (-5°C to +65°C)
Working pressures are at +68°F (+20°C). Higher
temperatures reduce the available working pressure. See
the PVC and Thermoplastic Temperature/Pressure chart
on page 445.
Brand Method: Series 160: Black ink
Series 161: Not branded
Brand Example: Series 160: NEXAQUA BY PARKER NEXGEN (P/N) (ID)
X (OD) MAX WP XXX PSI AT 68°F (20°C) CANADA (DATE
CODE)
Industry Standards: None applicable
Applications: • Mild chemicals, water
• Golf courses, greenhouses, municipal parks
• Commercial lawn and garden, contractors, general
industrial
Vacuum: Not recommended
Packaging: Coils

! WARNINGS!
„ Couplings attached with bands or clamps may reduce the working pressure of the hose assembly to less than the maximum rated working
pressure of the hose. Refer to the NAHAD Industrial Hose Assembly Guidelines.
„ Working pressures are at +68°F (+20°C). Higher temperatures reduce the available working pressure. See the PVC and Thermoplastic
!
Temperature/Pressure chart on page 445.
