6004 Series

Straight Line Action Clamps | Product Overview

Features: Applications: Also Available:
• Similar in size to Model 604, with a solid body • Assembly See page MC-ACC-1 for accessories
• 50% more holding capacity than 604 • Checking fixtures
• May be mounted through a hole or in • Welding fixtures
a tapped hole. • Tensioning devices
• Locks over center in the extended and
retracted position

Covered under one or more U.S./International Patents

6004 6004-R
6004-MM 6004-MMR
with
DESTACO
®
Toggle Lock
Plus

Technical Information | Holding Capacities | Dimensions

Max. (M) Spindle Mounting
HC EF EF:AF Plunger
Model Holding Weight (pushing) Travel Plunger (Recom- Nut
Capacity Thread mended) (Supplied)

AF 6004 [0.81lb] 5/16-18 207203 606104
6004-MM [450 lbf] 0,37kg 38 M8 207203-M 606104-M

6004-R 2000 N [0.89lb] 14.4:1 [1.50] 5/16-18 207203 606104
6004-MMR 0,40kg M8 207203-M 606104-M
HC = Holding Capacity, EF = Exerting Force, AF = Applied Force
[.88]
22,2
[1.00]
25,4 [1.84]
46,8
6004 3/4-16
6004-MM M20X1,5
[2.81]
71,4
[.75] DESTACO
®
19,1
TOGGLE LOCK
PLUS OPTION
PLUNGER 6004-R / 6004-MMR
TRAVEL
[.13]
Ø[.50] 3,2
Ø12,7

PLUNGER
6004 - 25,4 [1.00] THREAD [.25] [4.21]
6004-MM - 30,0 [1,18] M 6,4 107 mm [INCH] mm [INCH]
[1.00]
25,4 THIRD ANGLE FIRST ANGLE
[1.35] PROJECTION PROJECTION
34,2
[5.52]
140,1
