Page 142 - Wieland - Selos/Fasis

Accessories

Tools

Wire entry guides Description Type Part No. Std. Pack
2
• For conductors with cross sections smaller 1.5 mm , 4 mm wide
2
than 1 mm 2 for 0.13 – 0.2 mm wires LEL 1,5/1 WEISS 05.564.4253.0 10
for 0.25 – 0.5 mm wires LEL 1,5/2 GRAU 05.564.4353.0 10
2
2.5 mm , 5 mm wide
2
for 0.13 – 0.2 mm wires LELN 2,5/1 WEISS 05.564.3755.0 100
2
for 0.25 – 0.5 mm wires LELN 2,5/1 GRAU 05.564.3855.0 100
2
2
for 0.75 – 1.0 mm wires LELN 2,5/1 SCHWARZ 05.564.3955.0 100
4 mm , 6 mm wide
2
for 0.13 – 0.2 mm wires LEL 4/1 WEISS 05.561.8553.0 100
2
for 0.25 – 0.5 mm wires LEL 4/2 GRAU 05.561.8653.0 100
2
2
for 0.75 – 1.0 mm wires LEL 4/3 SCHWARZ 05.561.8753.0 100

Notching tool Description Type Part No. Std. Pack
for cross connectors Notching tool AKW /A 95.300.0500.0 1
• For 1.5 mm , wide 4 mm wide
2
• For 2.5 mm , 5 mm wide
2
• For 4 mm , 6 mm wide
2

Screwdrivers Description Type Part No. Std. Pack
1.5 mm , 4 mm wide
2
Uninsulated, long and straight DIN 5264 A 0,4x2,5 06.502.4300.0 5
2.5 mm , 5 mm wide
2
Uninsulated, long and straight DIN 5264 B 0,6x3,5 06.502.4000.0 10
Uninsulated, short and straight DIN 5264 B 0,6x3,5 M 06.502.5000.0 10
Uninsulated, long and angled DIN 5264 B 0,6x3,5 W 05.502.4100.0 10
Uninsulated, short and angled DIN 5264 B 0,6x3,5 MW 05.502.4000.0 10
4 mm , 6 mm wide
2
Uninsulated, long and straight DIN 5264 B 0,6x3,5 06.502.4000.0 10
Uninsulated, short and straight DIN 5264 B 0,6x3,5 M 06.502.5000.0 10
Uninsulated, long and angled DIN 5264 B 0,6x3,5 W 05.502.4100.0 10
Uninsulated, short and angled DIN 5264 B 0,6x3,5 MW 05.502.4000.0 10
6 mm , 8 mm wide DIN 5264 B 0,6x4 06.502.4100.0 5
2
2
10 mm , 10 mm wide DIN 5264 B 0,6x4 06.502.4100.0 5
16 mm , 12 mm wide DIN 5264 B 1x5,5 06.502.4200.0 5
2
35 mm , 16 mm wide DIN 5264 B 1x5,5 06.502.4200.0 5
2

142
